Bentel BW-PGH - PowerG Host transceiver compatible with Absoluta Plus alarm control panels

Name: Bentel BW-PGH - PowerG Host transceiver compatible with Absoluta Plus alarm control panels
Brand: BENTEL SECURITY
SKU: BW-PGH
Price: 126.32 EUR
Availability: OutOfStock

Out of stock

SKU: BW-PGH

Notify me when this product is in stock

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Are you a Reseller? Register Here

Description

Bentel BW-PGH PowerG Host transceiver is a wireless transceiver compatible with the new Absoluta Plus control panels. This device, thanks to the advanced PowerG Host technology , allows you to connect wireless alarm devices such as BW-SRI, BW-SRO, BW-REP and many others to the Absoluta Plus alarm control unit.

Data sheet

Current Draw: 60mA.
Voltage: Draws current from the Absoluta Plus/Absoluta 630 alarm controller (10.8VDC to 12.5VDC) - (Limited Power Supply)
Frequency: 868MHz (BW-PGH).
Zones - can receive signals from up to 128 wireless zones. Also supports up to 32 wireless keys.
Supervisory - programmable supervisory window.
Can be wired up to 230 m from the main panel with 0.34 mm2 wire.
Connects to Tranceiver Bus.
Compatibility: The BW-PGH is used with Absoluta Plus/Absoluta 630 alarm panels
Operating temperature: EU= -10°C – +55°C
Relative humidity: 93% non-condensing.
Separate, built-in wall and case tampers.
