| Camera |
| Image sensor | 1/2.7 inch CMOS |
| Maximum. Resolution | 2960 (H) × 1688 (V) |
| rom | 128MB |
| RAM | 256MB |
| Scanning system | Progressive |
| Electronic shutter speed | Auto/Manual 1/3 s–1/100,000 s |
| minimum lighting | 0.007 [email protected] (color, 30 IRE) 0.0007 [email protected] (black and white, 30 IRE) 0 lux (Illuminator on) |
| S/N ratio | >56dB |
| Lighting distance | Up to 30 m (98.43 ft) (IR) |
| Illuminator on/off control | Car; Manual |
| Illuminator number | 1 (IR LED) |
| Pan/Tilt/Rotate range | Pan: 0°–360° Inclination: 0°–78° Rotation: 0°–360° |
| Lens |
| Lens type | Fixed focal length |
| Lens attachment | M12 |
| Focal length | 2.8mm; 3.6mm |
| Maximum. Opening | F1.6 |
| Field of view | 2.8mm: H: 111°; V: 58°; D: 132° |
| Iris control | Fixed |
| Close focusing distance | 2.8mm: 1.1m (3.61ft) |
| DORI Distance | Lens | Detect | To observe | Recognize | Identify |
| 2.8mm | 63.6 million (208.66 feet) | 25.4 million (83.33 feet) | 12.7 million (41.67 feet) | 6.4 million (21.00 feet) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) to define the ability of a person watching the video to distinguish people or objects within a covered area. The numbers in this table do not reflect the distances of the intelligent functions. For distances of intelligent functions, refer to the installation and commissioning manual/design tool. |
| Intelligence |
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support classification and accurate detection of vehicles and people) |
| Smart search | Work with Smart NVR to perfect intelligent search, event extraction, and event video merging |
| video |
| Video compression | H.265; H.264; H.264H; H.264B; MJPEG (supported by substream only) |
| Smart codec | Smart H.265+; Intelligent H.264+ |
| Video frame rate | Main stream: 2960 × 1668@(1–20 fps)/2688 × 1520@(1–25/30 fps) substream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values indicated above are the maximum values. frame rate of each stream; for multiple streams, the values will be subject to the total encoding capacity. |
| Flow capacity | 2 streams |
| Resolution | 2960×1668 (2960×1668); 2880×1620 (2880×1620); 2688×1520 (2688×1520); 3M (2048×1536); 2304×1296 (2304×1296); 1080p (1920×1080); 1.3 million (1280 × 960); 720p (1280×720); D1 (704×576/704×480); VGA (640×480); CIF (352×288/352×240) |
| Bit rate control | CBR/VBR |
| Video bitrate | H.264: 32kbps–8192kbps H.265: 12kbps–8192kbps |
| Day night | Auto(ICR)/Color/B/W |
| BLC | YES |
| HLC | YES |
| WDR | 120dB |
| White balance | Car; natural; Street lamp; outdoors; Manual; regional custom |
| Gain control | Car; Manual |
| Noise reduction | 3D No |
| Motion detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Intelligent lighting | YES |
| Image rotation | 0°/90°/180°/270° (Support 90°/270° at 2688 × 1520 resolution and below) |
| Mirror | YES |
| Privacy masking | 4 areas |
| Audio |
| Built-in MICROPHONE | YES |
| Audio compression | G.711a; G.711Mu; PCM; G.726 |
| Alarm |
| Alarm event | No SD card; SD card full; SD card error; disconnection from the network; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
| Net |
| Network port | RJ-45 (10/100 Base T) |
| SDKs and APIs | YES |
| Network protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour; P2P |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI |
| User/Guest | 20 (total bandwidth: 48M) |
| Warehousing | FTP; SFTP; Micro SD card (support max. 256GB); NAS |
| Navigator | MEANING WHAT Chrome Firefox |
| Management software | SmartPSS Lite; DSS; DMSS |
| Mobile customer | iOS; Android |
| Cyber security | Configuration encryption; reliable execution; Digest; security logs; WSSE; account blocking; system registry; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted update; trusted boot; firmware encryption; generation and import of X.509 certification |
| Certification |
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 and CAN/CSA C22.2 No. 62368-1-14 |
| Power |
| Power supply | 12VDC/PoE (802.3af) |
| Energy consumption | Base: 2.2W (12V DC); 2.9W (PoE) Maximum. (H.265+ max resolution + max flow+ WDR + IR intensity + IVS): 4.1W (12V DC); 5.0W (PoE) |
| Environment |
| operating temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating humidity | ≤95% |
| Storage temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage humidity | ≤95% |
| Protection | IP67 |
| Structure |
| Casing material | Inner core: metal Cover: metal Decorative ring: plastic Quick Install Mounting Plate: Metal |
| Product dimensions | 99.1mm × Φ121.9mm (3.90" × Φ4.80") |
| Net weight | 0.48 kg (1.06 lb) |
| Gross weight | 0.68kg (1.50lbs) |
