Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions. The NVR5000-EI series offers outstanding performance and high-grade recording technology that make it ideal for IP video surveillance applications. It has a powerful processor, that offers high access and forwarding bandwidth and strong decoding capabilities that together produce unimpeded streams. Thanks to its built-in AI chip and Dahua's advanced deep learning algorithms, the NVR supports a variety of AI functions, such as high-precision face recognition and perimeter protection. They shorten the response time to events and make videos more interactive. This NVR is compatible with numerous third-party devices, making it a great solution for surveillance systems that work with Video Management Software (VMS).
AcuPick
This industry-leading search technology effectively utilizes both front-end and back-end intelligence to help with searching through massive video data to quickly and conveniently locate targets with greater precision.
Perimeter Protection
Automatically filtering out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to perform secondary recognition for the targets. Improving alarm accuracy.
Face Detection
Face detection is to detect if there is any human face appearing in the video. This technology adopts a deep learning algorithm to support face detection, tracking, optimization and capturing, and then output the best face snapshot.
Face Recognition
Dahua Face Recognition technology extracts the features of captured faces and compares them with those in face database to recognize the person identity.
Heat Map by Camera
Dahua heat map technology is used to display the crowd density and people appearance probability. Export and display the crowd status by different colors. Generally, the crowd status is the statistics of people quantity in space and time dimensions.
ANPR by Camera
With deep learning algorithm, Dahua ANPR technology can recognize the number plate information of vehicles in the image with ANPR cameras. Support blocklist/allowlist mode, searching target vehicles from recorded video.
SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.
Features
- Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
- Max. decoding capability: 32 × 1080p@30 fps or 8 × 8MP@30 fps.
- Max. 384 Mbps incoming/recording/outgoing bandwidth.
- Support AcuPick with Max. 16-Channel.
- Support N+M cluster.
- AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus.
- AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
- Security baseline 2.3.
Standard:
TCP/IP
Supported resolutions:
max. 32 Mpx
Video outputs:
1 pcs HDMI 4K
1 pcs VGA
Audio support:
8 Channels - Audio from cameras
Bi-directional audio streaming support
Audio inputs:
1 pcs CINCH
Audio outputs:
1 pcs CINCH
Image compression method:
Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG
Bitrate:
max. 384 Mbps
Supported hard drives:
2 x 16 TB SATA
Recording modes:
Manual, Sensor, Motion detection, Schedule
External storage devices backup:
Backup to USB drive (pendrive, external drive)
Searching and playback the records:
Records searching: by time and events type. Records playback: forward, backward, fast, slow
Advanced searching (to the one second accuracy)
Smart Playback function
Records playback from max. 8 channels in the same time @ 1080p (without AI)
Records playback from max. 8 channels in the same time @ 1080p (AI)
Network interface:
1 x RJ-45 10/100/1000 Base-TX
Network functions:
Full support via network, Remote records copying, Web Server built-in
Network protocols:
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UDP; SNMP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; PPPoE; FTP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCS
ONVIF:
22.06
Default IP address:
192.168.1.108
Default admin user / password:
admin / - The administrator password should be set at the first start
Mobile phones support:
Port no.: 37777 or access by a cloud (P2P)
Android: Free application DMSS
iOS (iPhone): Free application DMSS
Web browser access ports:
80, 37777
PC client access ports:
37777
Mobile client access ports:
37777
USB:
2 pcs USB 2.0
1 pcs USB 3.0
Serial ports:
RS-485, RS-232
Alarm inputs / outputs:
4 / 2
PTZ control:
IP Speed Dome Cameras
RS-485 - PELCO-D/P and others
Motion Detection:
Yes
Intelligent Image Analysis:
Yes
Main features:
Intelligent Image Analysis : crossing the line (tripwire), intrusion, face detection
SMD PLUS - searching for an object classified as: human, motor vehicle
Filtering of false alarms based on the recognition of persons and vehicles
Face recognition
Face analysis: determination of sex, age and characteristic elements of appearance (glasses, facial hair, mask)
Support for up to 20 face databases, including 20 000 face images
In the base other than face photography, can also be stored such information as: name, sex, date of birth, nationality, address, ID number
Intelligent face search by metadata of different targets or uploading pictures of faces to the device and comparing them with recorded faces by similarity
Privacy zones
Cooperation with POS (Point of Sale) terminals
Functions implemented in cooperation between the recorder and cameras that support these functions :
ANPR
Authorized and unauthorized license plate lists: up to 20 000 records
counting people / vehicles
crowd gathering estimation
heat map
metadata handling - automatic photo taking and collection of information enabling the subsequent identification of people and vehicles that triggered the alarm (clothing, silhouette, face, features of motor and non-mechanical vehicles)
Mouse support:
Yes
IR remote controller in the set:
No
Power supply:
100 ... 240 V AC @ 47 / 63 Hz
PoE Port:
8 ports, 10/100 Mbps, IEEE 802.3 af/at, 1-8 ports support ePoE
Power Consumption
Total output of NVR is ≤ 10 W (without HDD) Total output power of PoE is 130 W, the maximum output power of a single port is 25.5W
Power consumption:
max. 10 W (without HDD)
Operation temp:
-10 °C ... 55 °C
Weight:
2.57 kg
Dimensions:
375.0 mm × 329.4 mm x 53.0mm (14.76" × 12.97" × 2.09") (W × D × H)
Supported languages:
Polish, English, Bulgarian, Czech, Finnish, Greek, Romanian, Serbian, Slovenian, Hungarian
Manufacturer / Brand:
DAHUA
