FAAC SOLID KIT 10561644
Automation for up and over doors, ideal for garages for domestic use.
Anti-crushing safety: electronic device for torque adjustment and ENCODER
Integrated microswitch limit switches for greater frequency of use.
Internal release and provision for external release with customized key.
Warning: telescopic arms and transmission pipes not included in the package.
The SOLID kit 230V package includes:
Qty
Description
Code
1
550 ITT electromechanical actuator with built-in electronic equipment and encoders
110549
1
Fixing beam 1.3 m
included
1
External unlocking with personalized keys from n. 1 to n. 50
424550001-50
1
Plug-in receiver 1 channel RP 433 SLH
787824
1
Transmitter 2 channels XT2 433 SLH LR
787007
1
"FAAC automatic" sign
Engine features
Template 550 ITT Power supply voltage 220-240V ~ 50/60 Hz Electric motor Asynchronous single phase Max power 350 W Couple max 300 Nm (*) Angular speed max 12 ° / s (*) Opening time 15 s Encoder Magnetic Operating ambient temperature -20 ° C to +55 ° C Thermal protection 140th Degree of protection For internal use only (IP31) Weight 7.5 Kg Dimensions (LxPxH) 670 x 175 x 120 mm Max door weight 10 Kg / sqm Electronic equipment E550 incorporated Frequency of use S3 - 30%
(*) data referred to 230V ~ 50Hz (**) For overhead doors with width from 3 to 4 m (height 3 m) use a 550 ITT actuator and a 550 Slave. In this case the electronic equipment E550 incorporated in the ITT 550 also manages the 550 Slave. The same applies to the L. version
Ean
8055195027204
Shipping
Shipping 24/48H
Warranty
2 year warranty
Garage door
basculante
Garage Size
from 10 to 14 m²
Power supply
230v
