Hikvision Ax Pro DS-PDMCK-EG2-WE(B) Magnetic contact + shock Opening detector, Combined detection 2 Inputs (NC/NO)

Name: Hikvision Ax Pro DS-PDMCK-EG2-WE(B) Magnetic contact + shock Opening detector, Combined detection 2 Inputs (NC/NO)
Brand: HIKVISION
SKU: DS-PDMCK-EG2-WE(B)
Price: 35.62 EUR
Availability: OutOfStock

Out of stock

SKU: DS-PDMCK-EG2-WE(B)

Notify me when this product is in stock

This form is protected by reCAPTCHA - the Google Privacy Policy and Terms of Service apply.

Are you a Reseller? Register Here

Description

The Hikvision DS-PDMCK-EG2-WE(B) is a multifunctional wireless magnetic sensor , designed to detect door/window opening and intrusion attempts by shock and tilt . It is equipped with a 868 MHz Tri-X bidirectional radio module , AES-128 encryption and two wired inputs (NC/NO/Pulse) for external sensors.

Easily installed, it is fully configurable remotely via app . Thanks to its high sensitivity and anti-jamming frequency hopping function, it ensures stable communication up to 1.6 km in open field .
Ideal for indoor protection in residential, retail or office environments.

Data sheet

Characteristic Value

Model	DS-PDMCK-EG2-WE(B)
Brand	Hikvision
Functions	Magnetic contact + shock + tilt
Compatible System	AX PRO
Communication Type	Tri-X Wireless Two-Way
Frequency	868MHz
Radio range (in open air)	Up to 1.6 km
Encryption	AES-128
Wired input	NC, NO, pulse counting
Maximum magnetic contact distance	43mm
Shock sensitivity	8 levels
Tilt sensitivity	Up to 25°
Configuration	Remotely via App
LED Indicators	Green (MC), Orange (tilt), Red (shock), Blue (alarm)
Tamper protection	Front and back
Power supply type	1 CR123A battery (3V)
Battery life	Up to 3 years (standby)
Main unit dimensions	24 × 104 × 24.4 mm
Magnet dimensions	13 × 34.4 × 11.4 mm
Weight	60 g
Operating temperature	-10°C ~ +55°C
Operating humidity	10% – 90%
Installation	Indoor

More Information

SKU Padre	DS-PDMCK-EG2-WE(B)
Ean	6954273659714
Shipping	Shipping 24/48H
Warranty	3 years warranty
Colore	White
Tecnologia Radio	Wireless 868
Contact Type	A vista
Color	White
