Shipping 24/48H

VORTICE 12346 devintalized heat recuperator VMC HRW 30 MONO EVO HCS

Name: VORTICE 12346 devintalized heat recuperator VMC HRW 30 MONO EVO HCS
Brand: VORTICE
SKU: VOR0000012436
Price: 214.38 EUR
Availability: InStock

In stock

SKU: VOR0000012436

Are you a Reseller? Register Here

Description

decentralized heat recovery ventilation unit:

Application: Ideal for residential and commercial premises in new construction or buildings undergoing renovation to improve energy efficiency and prevent excess humidity and mold formation on walls.
Structure: Made of resistant anti-shock and anti-UV plastic resin.
Nominal diameter: 100 mm.
Heat exchanger: Ceramic type with hexagonal cells with high heat exchange efficiency up to 90% at minimum air flow.
Fan motor: high efficiency EC with five operating speeds to maximize performance or reduce noise and consumption.
Relative humidity probe: Integrated into the product to monitor and regulate the humidity in the environment.
One-way remote control: To set parameters and view useful information, including turning power on and off, selecting operating modes, fan speeds, relative humidity levels to activate Boost speed and "Night" mode, and signaling the saturation of the filters.
Operating modes: Continuous ventilation with heat recovery, extraction air ventilation only, air intake ventilation only, automatic (managed by the relative humidity sensor), and "Night" mode (ventilation at minimum speed when the temperature drops light).
Air filters: Includes an IsoCoarse 65% and a dust pre-filter, both easily removable and washable.
Quick closing system of the air supply: Integrated for easy maintenance.
External rubber grille: Can be installed from the outside or inside of the wall without the need for external scaffolding.
Anti-insect net: Can be inserted into the duct to prevent insects from entering the environment

Data sheet

Filter class	ISOCoarse 65%
Max absorbed current (A)	0.04A
Nominal Duct Diameter (mm)	100 mm
Frequency (Hz)	50-60Hz
Isolation	2nd class
Weight kg)	3.10kg
Max absorbed power (W)	4W
Maximum continuous operating ambient temperature (°C)	30°C
Voltage (V)	220-240V
Max recovery efficiency (%)	90%
Max flow rate at max speed. (l/s)	10.5 l/s
Max flow rate at max speed. (m³/h)	38 m³/h
Max flow rate at min speed. (l/s)	1.7 l/s
Max flow rate at min speed. (m³/h)	6 m³/h
Sound power Lw [dB (A)] - max speed	66.8 dB(A)
Sound power Lw [dB (A)] - min speed	36.6 dB(A)
Sound power Lw [dB(A)] - med speed	49.5 dB(A)
Max pressure at max speed. (mmH2O)	13.7 mmH2O
Max pressure at max speed. (Pa)	130 Pa
Max pressure at min speed. (mmH2O)	1 mmH2O
Max pressure at min speed. (Pa)	10 Pa
Sound pressure Lp [dB (A)] 3m - max speed	49.2 dB(A)
Sound pressure Lp [dB (A)] 3m - med speed	32.0 dB(A)
Sound pressure Lp [dB (A)] 3m - min speed	19.1 dB(A)

More Information

Ean	8010300124360
Shipping	Shipping 24/48H
Warranty	2 year warranty
Materials	resina plastica anti-urto e anti-UV.
Nominal diameter	100mm
Installazione	a incasso
Colore	White
Watts	4
Smart home	No
Waterproof	IP20
Packaging	1
Voltage	AC:200-240V
Dimensions	D100

Reviews (0)

Product Attachments
